Galvanized Welded Wire Mesh is a type of wire product made from high-quality iron wire, welded together at intersections, and then coated with zinc for added durability and resistance. This protective coating, or 'galvanization', helps guard the welded wire mesh against corrosion and rust, ensuring its longevity.
The carbon steel wires in this type of welded wire mesh are arranged horizontally and vertically, creating a grid-like structure, and all the intersections are firmly welded together. The precision and stability offered by welded joints make the welding structure robust and ensure uniformity.
Specification
Galvanized welded wire mesh rolls are made by welding high-quality low-carbon steel wires together using an electric welding machine, creating a robust grid structure. The galvanized welded wire mesh is then coated with a layer of zinc to provide rust prevention, making the galvanized welded wire mesh suitable for both indoor and outdoor use. The galvanization process can be done before or after the welding process, with the latter offering a more comprehensive protection as the entire surface, including the welding joints, is covered with zinc.
 |  |
The galvanized welded wire mesh fences are usually cut by our wonderful workers and rolled into rolls for packaging and transportation. SUNSHINE Group want the customers to be able to choose the appropriate width and length of galvanized welded wire mesh rolls according to your needs.
3ft(0.9m) x 50ft(15.24m) welded wire fence,4ft(1..21m) x 50ft welded wire fence,5ft（1.52m） x 50 ft welded wire fence,6ft(1.83m) x 50 ft welded wire fencing,4ft x 100 ft welded wire fence,6ftx 100 ft welded wire fencing are widely used for construction projects!
Here is the mesh size of the welded wire mesh fencing rolls:
| Mesh | Mesh | Cardinal Number | Wire Range |
| MM | Inch | MM-MM | |
| 6.35X6.35 | 1/4"X1/4" | 4 | 0.45--0.70 |
| 8.47X8.47 | 1/3"X1/3" | 3 | 0.50--0.80 |
| 9.53X9.53 | 3/8"X3/8" | 2.6 | 0.50--0.90 |
| 12.7X12.7 | 1/2"X1/2" | 2 | 0.50--1.20 |
| 15.9X15.9 | 5/8"X5/8" | 1.6 | 0.60--1.20 |
| 19.1X19.1 | 3/4"X3/4" | 1.33 | 0.60--1.60 |
| 25.4X25.4 | 1"X1" | 1 | 0.65--1.90 |
| 38.1X38.1 | 1-1/2"X1-1/2" | 0.67 | 1.00--2.00 |
| 50.8X50.8 | 2"X2" | 0.5 | 1.20--2.10 |
| 76.2X76.2 | 3"X3" | 0.333 | 1.70--2.50 |
| 101.6X101.6 | 4"X4" | 0.25 | 1.70--2.50 |
| 25.4x12.7 | 1"x1/2" | 1.5 | 0.65--1.60 |
| 50.8x25.4 | 2"x1" | 0.75 | 1.20--1.90 |
| 63.5x50.8 | 2-1/2"x2" | 0.45 | 1.70--2.50 |
| 76.2x50.8 | 3"x2" | 0.42 | 1.70--2.50 |
| 101.6x50.8 | 4"x2" | 0.375 | 1.70--2.50 |
| 101.6x63.5 | 4"x2-1/2" | 0.325 | 1.70--2.50 |
| 101.6x76.2 | 4"x3" | 0.29 | 1.70--2.50 |
Corrosion Resistance: The galvanized coating protects the galvanized welded wire mesh from rust and extends its lifespan, especially in outdoor environments.
Uniformity: The galvanized welded wire mesh has a consistent pattern, which ensures even distribution of stress and load-bearing capacity.
Versatility: Galvanized welded wire mesh is used in a variety of applications such as construction, fencing, agriculture, and animal enclosures due to its strength and durability.
Cost-Effectiveness: Compared to other types of wire mesh, galvanized welded wire mesh offers a good balance of cost and performance.
Safety: The smooth, uniform surface reduces the risk of injury, making the welded wire mesh safe for various applications.
We use wooden and steel packing to ensure the quality of our products. The size of the container depends on the size of the goods.
