PVC coated iron wire is made of black iron wire, galvanized wire, copper wire, stainless steel wire, through deep processing so that the PVC and metal wire firmly bonded together. PVC coated iron wire is a versatile and durable option that provides enhanced protection and longevity compared to uncoated wire. Its resistance to corrosion and moisture makes the PVC coated iron wire suitable for a wide range of industries and applications.
Specification
Materials before PVC coating: | steel wire, galvanized wire, redrawing wire,annealed wire, etc. |
|---|---|
| Surface: | plastic coating. |
| Color: | green, blue, red, white and black; other colors also available on request. |
| Wire diameter before coating: | 0.6 mm-4.0 mm (8-23 gauge). |
| Wire diameter with coating: | 0.9 mm-5.0 mm (7-20 gauge) |
| Thickness: | 0.4 mm-1.5 mm |
| Wire diameter tolerance: | ±0.05 mm. |
Features:
Corrosion resistance: The pvc coating acts as a barrier against moisture, chemicals, and other environmental factors that can cause corrosion, significantly extending the lifespan of the PVC coated iron wire in outdoor and harsh environments.
Abrasion resistance: The PVC layer offers protection against physical wear and tear, enhancing the durability of the wire in applications where it may be exposed to friction or impact.
Color options: PVC coated iron wire comes in a variety of colors, allowing for aesthetic versatility in design and enabling the wire to blend with or contrast against its surroundings depending on the application.
Size chart(wire diameter after coating):
Wire Gauge | SWG(mm) | BWG(mm) | Metric(mm) |
8 | 4.05 | 4.19 | 4.00 |
9 | 3.66 | 3.76 | 4.00 |
10 | 3.25 | 3.40 | 3.50 |
11 | 2.95 | 3.05 | 3.00 |
12 | 2.64 | 2.77 | 2.80 |
13 | 2.34 | 2.41 | 2.50 |
14 | 2.03 | 2.11 | 2.50 |
15 | 1.83 | 1.83 | 1.80 |
16 | 1.63 | 1.65 | 1.65 |
17 | 1.42 | 1.47 | 1.40 |
18 | 1.22 | 1.25 | 1.20 |
19 | 1.02 | 1.07 | 1.00 |
20 | 0.91 | 0.84 | 0.90 |
21 | 0.81 | 0.81 | 0.80 |
22 | 0.71 | 0.71 | 0.70 |
Packing:
Plastic inner and outer knitting, inner plastic outer hemp, carton, pallet
