0.8mm-4.5mm high tensile round galvanized iron wire

Galvanized iron wire is a type of binding wire that has been coated with zinc to resist corrosion and rust. The process of galvanization(electro-galvanized,hot dipped galvanized) involves creating a protective layer on the surface. This makes the galvanized iron wire suitable for outdoor use and in environments where moisture and other corrosive elements are present. The galvanized iron wire is commonly used in fencing, binding, and construction reinforcement due to its durability and cost-effectiveness compared to stainless steel alternatives.

Inquire Now

Specification

High tensile galvanized iron wire, also known as HTGI wire, is a type of metal wire made from low carbon steel wire. This galvanized iron wire is known for its high strength and durability, which is achieved by the process of galvanization.

The galvanization process involves coating the iron wire with a protective layer of zinc to prevent rusting and corrosion. This makes the high tensile galvanized iron wire highly resistant to tough weather conditions and heavy usage, hence extending its life span.

The galvanized iron wire is often used in various industries, including construction, agriculture, and manufacturing. It's commonly used for fencing, net making, cable armoring, and other applications where high strength and durability are required. The high tensile strength of the galvanized iron wire also makes it suitable for jobs where a high degree of tension is needed.

Features:

Corrosion Resistance: The zinc coating protects the iron wire from rust, which extends the galvanized iron wire's lifespan and maintains its appearance for a longer time.
High Tensile Strength: Galvanized iron wire is known for its high tensile strength. This makes the galvanized iron wire suitable for applications that require a high degree of tension and strength, such as fencing, netting, or cable armoring.
Durability: The combination of high tensile strength and corrosion resistance makes galvanized iron wire highly durable. The galvanized iron wire can withstand harsh weather conditions and heavy usage, which makes the galvanized iron wire ideal for outdoor applications

0.8mm-4.5mm high tensile round galvanized iron wire

Size chart:

No.	Diameter(mm)	Tensile Strength(n/mm2)	Zinc Thickness(g/m2)	Weight of unit coil(kg)
5.5~6#	5.00	300~1500	30~100	400~600
7#	4.57	300~1500	30~100	400~600
8#	4.19	300~1500	30~100	400~600
9#	3.76	300~1500	30~100	400~600
10#	3.40	300~1500	30~100	400~600
11#	3.05	300~1500	30~100	400~600
12#	2.77	300~1500	30~80	400~600
13#	2.41	300~1500	30~80	400~600
14#	2.11	300~1500	30~80	400~600
15#	1.83	300~1500	30~80	400~600
16#	1.65	300~1500	30~80	25~500
17#	1.47	300~1500	30~80	25~500
18#	1.24	300~1500	≥12	25~500
19#	1.07	300~1500	≥12	25~500
20#	0.89	300~1500	≥12	25~400
21#	0.81	300~1500	≥12	25~400
22#	0.71	300~1500	≥12	25~200
23#	0.64	300~1500	≥12	25~150
24#	0.56	300~1500	≥12	10~150
25#	0.51	300~1500	≥12	10~100
26#	0.46	300~450	≥12	10~50
27#	0.41	300~450	≥12	10~50
28#	0.36	300~450	≥12	10~50
29#	0.33	300~450	≥12	10~50
30#	0.30	300~450	≥12	5~20
30.5#	0.28	300~450	≥12	5~20
