China factory supply galvanized iron wire

Galvanized iron wire is a type of binding wire that has been coated with zinc to resist corrosion and rust. The process of galvanization(electro-galvanized,hot dipped galvanized) involves creating a protective layer on the surface. This makes the galvanized iron wire suitable for outdoor use and in environments where moisture and other corrosive elements are present. The galvanized iron wire is commonly used in fencing, binding, and construction reinforcement due to its durability and cost-effectiveness compared to stainless steel alternatives.

Inquire Now Next Product

Specification

Product name	galvanized low carbon steel wire,galvanized mild steel wire
Material	high quality iron wire Q195 Q245
Surface Treatment	Hot-dipped Galvanized/Electro-Galvanized
Processing Service	Welding, Bending, Cutting
Wire Diameter	0.56mm-5mm
Surface	Galvanised Zinc
Coil weight	5kg --- 500 Kg

Features:

Corrosion Resistance: The primary feature of galvanized iron wire is its resistance to corrosion. The zinc coating protects the underlying iron wire from the elements, preventing rust and extending its lifespan.
High Strength: Galvanized iron wires are known for their high tensile strength and durability. The galvanized iron wire can withstand high amounts of stress without breaking, making them suitable for heavy-duty applications.
Flexibility: Despite their strength, the galvanized iron wires are also quite flexible. The galvanized iron wires can be bent, twisted, and turned without breaking, which makes them easy to work with in a variety of settings.

Galvanized iron wires are used in a wide range of applications, from fencing and net making to binding materials in construction.

Anti rust high quality galvanized iron wire

Size chart:

No.	Diameter(mm)	Tensile Strength(n/mm2)	Zinc Thickness(g/m2)	Weight of unit coil(kg)
5.5~6#	5.00	300~1500	30~100	400~600
7#	4.57	300~1500	30~100	400~600
8#	4.19	300~1500	30~100	400~600
9#	3.76	300~1500	30~100	400~600
10#	3.40	300~1500	30~100	400~600
11#	3.05	300~1500	30~100	400~600
12#	2.77	300~1500	30~80	400~600
13#	2.41	300~1500	30~80	400~600
14#	2.11	300~1500	30~80	400~600
15#	1.83	300~1500	30~80	400~600
16#	1.65	300~1500	30~80	25~500
17#	1.47	300~1500	30~80	25~500
18#	1.24	300~1500	≥12	25~500
19#	1.07	300~1500	≥12	25~500
20#	0.89	300~1500	≥12	25~400
21#	0.81	300~1500	≥12	25~400
22#	0.71	300~1500	≥12	25~200
23#	0.64	300~1500	≥12	25~150
24#	0.56	300~1500	≥12	10~150
25#	0.51	300~1500	≥12	10~100
26#	0.46	300~450	≥12	10~50
27#	0.41	300~450	≥12	10~50
28#	0.36	300~450	≥12	10~50
29#	0.33	300~450	≥12	10~50
30#	0.30	300~450	≥12	5~20
30.5#	0.28	300~450	≥12	5~20

Packing:

Inner with plastic film and outer with woven bags
