Hot sale GI iron wire for binding

Galvanized iron wire is a type of binding wire that has been coated with zinc to resist corrosion and rust. The process of galvanization(electro-galvanized,hot dipped galvanized) involves creating a protective layer on the surface. This makes the galvanized iron wire suitable for outdoor use and in environments where moisture and other corrosive elements are present. The galvanized iron wire is commonly used in fencing, binding, and construction reinforcement due to its durability and cost-effectiveness compared to stainless steel alternatives.

Inquire Now Next Product

Specification

GI iron wire means galvanized iron wire which made from high quality wire rods(SAE1008) and undergone hot-dipped or electro galvanization manufacturing process.

The raw material of galvanized iron wire is high-quality low carbon steel wire(Q195/Q235), so the galvanized iron wire has good strength and load-bearing capacity, able to adapt to various needs of construction projects. The surface of the galvanized iron wire after galvanization has a layer of zinc protective coating that does not easily react chemically with oxygen and water, therefore, the galvanized iron wire has excellent rust and corrosion resistance for outdoor use.

The galvanized iron wire are widely used as binding wire for construction and woodworking projects.

Hot sale GI iron wire for binding

Size chart:

No.	Diameter(mm)	Tensile Strength(n/mm2)	Zinc Thickness(g/m2)	Weight of unit coil(kg)
5.5~6#	5.00	300~1500	30~100	400~600
7#	4.57	300~1500	30~100	400~600
8#	4.19	300~1500	30~100	400~600
9#	3.76	300~1500	30~100	400~600
10#	3.40	300~1500	30~100	400~600
11#	3.05	300~1500	30~100	400~600
12#	2.77	300~1500	30~80	400~600
13#	2.41	300~1500	30~80	400~600
14#	2.11	300~1500	30~80	400~600
15#	1.83	300~1500	30~80	400~600
16#	1.65	300~1500	30~80	25~500
17#	1.47	300~1500	30~80	25~500
18#	1.24	300~1500	≥12	25~500
19#	1.07	300~1500	≥12	25~500
20#	0.89	300~1500	≥12	25~400
21#	0.81	300~1500	≥12	25~400
22#	0.71	300~1500	≥12	25~200
23#	0.64	300~1500	≥12	25~150
24#	0.56	300~1500	≥12	10~150
25#	0.51	300~1500	≥12	10~100
26#	0.46	300~450	≥12	10~50
27#	0.41	300~450	≥12	10~50
28#	0.36	300~450	≥12	10~50
29#	0.33	300~450	≥12	10~50
30#	0.30	300~450	≥12	5~20
30.5#	0.28	300~450	≥12	5~20
