Gi weaving chain link wire mesh for fencing

The galvanized chain link fence is a type of metal fence that is made from low carbon steel wire that has been coated with a layer of zinc. This process, known as galvanization, helps to prevent rust and corrosion, making the gi chian link fence more durable and longer-lasting. GI chain link fences are often used for residential, commercial, and industrial applications, such as backyards, schools, parks, and construction sites. Thegalvanised chain link fencing is easy to install, require minimal maintenance, and provide excellent security and visibility. With its strength, durability, and low cost, the galvanized chain link fence is a popular choice for those looking for a reliable and effective fencing solution.

Specification

GI chain link fencing introduction

Galvanized chain link fences are durable, cost-effective barriers made of low carbon steel wire coated with zinc to prevent rust. The GI chain link fencing offer excellent visibility, security, and low maintenance. Ideal for residential, commercial, and industrial applications, the GI chain link mesh provide a balance of strength and affordability, making the GI chain link fence a popular choice for various properties.

Product Namechain link fence,diamond wire mesh
Surface Treatmenthot-dipped galvanized,electro-galvanized,PVC coated
Weaving type
twisted edge,knuckle edge,twisted knuckle edge,flat edge
Mesh Size50x50mm, 60x60mm, 75x75mm, etc.
Wire Diameter2.8mm, 3.0mm, 3.2mm, 3.5mm, 4.0mm,etc
Height1.2m, 1.5m, 1.8m, 2.0m, 2.4m, etc.
Length9-18m based on the roll weight
Post Size75x1.5/2.0mm; 60x1.5/2.0mm; 48x1.5/2.0mm

Gi chain link fence sizes

Here is the galvanized chain link fence size chart:

Opening
1"
1.5"
2"
2-1/4"
2-3/8"
2-1/2"
2-5/8"
3"
4"
25mm
40mm
50mm
57mm
60mm
64mm
67mm
75mm
100mm
Wire diameter
18Ga - 13Ga
16Ga - 8Ga
18Ga-7Ga
1.2mm- 2.4mm
1.6mm - 4.2mm
2.0mm-5.00mm
Length of the roll
0.50M - 100M(or more)
Width of the roll
0.5M - 5.0M

Weaving chain link fence

Weaving the chain link fence involves a meticulous process using a weaving machine. The process starts with galvanized low carbon steel wire fed into the machine. The galvanized iron wire is twisted and interlocked in a zigzag pattern, forming the characteristic diamond shape. Each twist secures the iron wire, ensuring a tight and uniform GI chain link mesh. The edges are then knuckled or barbed for added security and safety. The woven chain link mesh is rolled into manageable lengths for easy transportation and installation. This method ensures a durable, flexible, and resilient fence suitable for various applications, from residential to commercial and industrial uses.


GI chain link fencing features

Durability and Strength: Made from low carbon steel wire that is hot-dipped galvanized, the GI chain link fence is highly resistant to rust and corrosion, ensuring a long service life.

Versatility: Galvanized chain link fences are used in a variety of settings, from residential yards to commercial and industrial properties, due to the ability to provide security and boundary definition.

Easy Installation: The GI chain link fences are relatively easy to install and require minimal maintenance. The process involves unrolling the mesh and attaching it to the fence posts, which can be done with simple tools.

Enhanced Visibility: The open weave design allows for good visibility through the GI chain link mesh, which can be an advantage for surveillance and aesthetic purposes.

Gi weaving chain link wire mesh for fencingGi weaving chain link wire mesh for fencing

Packing:

Both ends is wrapped with plastic cloth and mesh bag,and then into the container.Special packaging requests are also accommodated.


Summary

Sunshine Fencing is a leading wire mesh manufacturer based in Shijiazhuang City, China, specializing in a broad range of wire mesh solutions. With over 20 years of experience, we are renowned for our innovative approach and high-quality fence products that cater to industries such as agriculture, construction, mining, and packaging. Our state-of-the-art factory, spanning 50,000 square meters, is equipped with modern technology and advanced equipment. We proudly export to over 100 countries, with annual sales exceeding $60 million. Sunshine Fencing provides over 200 wire mesh solutions and is dedicated to delivering dependable and competitive products in the metal fence and steel wire manufacturing sector. Sunshine Fencing has supplied many clients over the world. You can consult our wire experts for more detailed solutions.
